high accuracy triaxial FOGs, three axis fiber gyroscope meter, IMU fiber gyors
The 3OG consists of body and heads, there are lines between the head and the body, the lines’ bending radius is demanded not less than 30mm. The gyros are recommended for using in an enclosed environment, and keep the gyros dried, otherwise, it will do damage to the precision and service life of gyros.
Performance Characteristics
| 1 | Parameter | |
| 2 | Range of measured angular rate, deg/sec | ±300 |
| 3 | Bias drift at fixed temperature, deg/h | 0.01 |
| 4 | Bias drift at temperature range from -40℃to +60℃, deg/h | 0.02 |
| 5 | Scale factor repeatability,% | 0.001 |
| 6 | Magnetic sensitivity | 0.03º/h/Gs |
| 7 | Random walk, deg/ | 0.001 |
| 8 | Bandwidth, Hz | 100 |
| 9 | Power consumption, W | 7 |
| 10 | Start up power consumption,W | 10 (without power off in first 3 secs) |
| 11 | Power supply | 5V±0.2 |
| 12 | Start up time, min | 1 |
| 13 | Operational temperature | -40℃to +60℃ |
| 14 | Dimensions, mm | 92×27(head)96×96×33(body) |
| 15 | Weight(net), kg | 1.5 |
| 16 | Output | RS422/RS485 |
| 17 | Shock | 30g 11msec half sin |
| 18 | Vibration | 20-2000 Hz 6g RMS |
Applications
●UAV/AUV/Helicopter ●Tactical nuclear weapons ●Aeronautics and astronautics
●Integrated navigation system ●inertial platform stabilizing ●Vehicle navigation
Dimensions
