Single Axis Fiber Optic Gyroscope Fog Fizoptika VG910F for Multi-Application Navigation

Name: Single Axis Fiber Optic Gyroscope Fog Fizoptika VG910F for Multi-Application Navigation
Brand: Shenzhen Fire Power Control Technology Co., LTD
SKU: MFOG-910
Price: 1000 USD
Availability: InStock

Brand Name:	Firepower
Model Number:	MFOG-910
MOQ:	1
Price:	1000$
Payment Terms:	L/C,D/P,T/T,Western Union
Supply Ability:	500/month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Range:

±240°/s

Zero-bias Stability( (10s, 1σ):

≤0.8°/h

Angular Random Walk:

≤0.02°/h

3dB Bandwidth:

≥1000Hz

Zero-bias Repeatability( (1σ):

≤0.8°/h

Scale Factor Nonlinearity:

≤1000ppm

Weight:

≤150g

Power Consumption:

≤1.5W

Packaging Details:

Sponge + Carton

Supply Ability:

500/month

Highlight:

single axis fiber optic gyroscope

fiber optic gyro for navigation

Fizoptika VG910F gyroscope

Product Description

Single Axis Fiber Optic Gyroscope FOG Fizoptika VG910F

Multi-Application Navigation Solution

Key Specifications

Attribute	Value
Range	±240°/s
Zero-bias stability (10s, 1σ)	≤0.8°/h
Angular random walk	≤0.02°/h
3dB Bandwidth	≥1000Hz
Zero-bias repeatability (1σ)	≤0.8°/h
Scale factor nonlinearity	≤1000ppm
Weight	≤150g
Power Consumption	≤1.5W

Product Overview

The MFOG-910 Micro-Nano Fiber Optic Gyroscope is a high-performance angular rate sensor integrating optical, mechanical, and electronic systems into a compact, robust unit. Utilizing the Sagnac effect with counter-propagating light beams in a micro-nano optical fiber coil, it delivers precise angular velocity detection.

Key Features

All-solid-state design with no moving parts for maximum reliability
Fast startup and long operational life (≥15 years)
Exceptional resistance to shock (≥1500g) and vibration (≥70g)
Compact size (≤150g) with low power consumption (≤1.5W)
High MTBF (≥100,000 hours calculated assessment)
Temperature-compensated for stable performance

Performance Parameters

Parameter	Specification
Scale factor (mV/°/s)	47±5
Power supply (V)	5+0.25+12
Impact resistance	≥1500g
Acceleration resistance	≥70g

Product Diagrams

Front View Outline Diagram

Side View Outline Diagram
