0.03°/H Inertial Bias Gyroscope Adopts RS422 Digital Communication Mode

1
MOQ
0.03°/H Inertial Bias Gyroscope Adopts RS422 Digital Communication Mode
Features Gallery Product Description Request A Quote
Features
Specifications
Product: Inertial Gyro Sensor
Range: ±450°/s
Stable Time: ≤30s
Bias Stability: ≤0.01°/h
Full Temp Zero Bias Stability: ≤0.03°/h
Bandwidth: ≥200Hz
High Light:

0.03°/H Bias Gyroscope

,

Inertial Bias Gyroscope

Basic Infomation
Place of Origin: CHINA
Brand Name: AVIC
Model Number: F98
Payment & Shipping Terms
Packaging Details: sponge+ box
Delivery Time: 20 days for sample
Payment Terms: T/T
Supply Ability: 50/month
Product Description

F98 1 axis FOG single axis fiber gyro sensor low b...

0.03°/h bias gyro inertial gyro angular rate sensor





Descriptions

F98 single-axis fiber optic gyroscope is an all-solid-state high-precision angular rate inertial sensor device integrating light, machine and electricity. The product has the characteristics of high precision and high reliability.


The product has zero bias stability less than or equal to 0.03°/h (10s smooth), response frequency bandwidth, ±5V DC power supply, power less than 5W, and adopts RS422 digital communication mode, which is convenient for users to use, and is an ideal inertial device to replace traditional mechanical gyroscopes.


Application areas: applications in high-precision inertial navigation systems, positioning and orientation systems, attitude measurement systems, servo stabilization systems, etc.



Applications

●UAV/AUV/Helicopter ●Tactical nuclear weapons ●Aeronautics and astronautics

●Integrated navigation system ●inertial platform stabilizing ●Vehicle navigation

0.03°/H Inertial Bias Gyroscope Adopts RS422 Digital Communication Mode 0

Performance Characteristics



No. Parameter F98-400 Unit Remarks
1 Maximum angular rate ±400 °/s
2 Scale factor

1650000×

(1±10%)

SP/°/s
3 Scale factor nonlinearity in room temperature ≤20 ppm
@25℃
4 Scale factor repeatability in room temperature ≤20 ppm @25℃
5

Scale factor repeatability in full

temperature



≤50 ppm -40℃~+70℃
6 Bias stability in room temperature ≤0.02

10s

1σ,°/h

@25℃
7 Bias repeatability in room temperature ≤0.01 1σ,°/h Bias
8 Bias repeatability in tull temperature ≤0.03 1σ,°/h -40℃~+70℃
9 Bias stability in changing temperature ≤0.015

100s

1σ,°/h

0.3℃/min,-40℃~+70℃
10 Random walk ≤0.003 °/
11 Activation time 0 min
12 Bias value during vibration/before vibration/after vibration ≤0.05 °/h
13 Bias value before/after vibration) ≤0.05 °/h
14 Magnetic sensitivity ≤0.01 °/h/Gs
15 Threshold value ≤0.02 °/h
16 Vibration

20Hz~2000Hz



Hz/10min
X Y Z

Vibration

spectrum


17 Impact 15g(3times) Half sine wave/11ms
±X ±Y ±Z



Dimensions

0.03°/H Inertial Bias Gyroscope Adopts RS422 Digital Communication Mode 1
