Fiber Optic Gyro
Created with Pixso.

Low Cost VG910 Similar Optical Gyroscope Single Axis

Low Cost VG910 Similar Optical Gyroscope Single Axis

Low Cost VG910 Similar Optical Gyroscope Single Axis

Brand Name: Firepower
Model Number: MFOG910
MOQ: 1
Price: negotiable
Payment Terms: T/T
Supply Ability: 100/month
Detail Information
Product Description
Detail Information
Place of Origin:
china
Product Name:
Single Axis Gyro
Measuring Range:
-250~+250º/s
Overall Dimensions:
82×82×20mm
Scale Factor:
7±0.5mvdeg/s
Supply Voltage:
5v
Random Vibration:
6.06g，20~2000Hz
Packaging Details:
sponge+box
Supply Ability:
100/month
Highlight:

5v Optical Gyroscope

,

Single Axis Gyro Sensor

,

2000Hz Fiber Optic Gyroscope

Product Description

VG910 Similar Optical Gyroscope New Fiber Optic Gyroscope Analog of Vg910 Gyro Sensor


Main performance parameters
See the main performance parameters of the product for details.

Serial number

Test item

Unit

Technical requirements
1 Overall dimensions mm 82×82×20
2 Scale factor mv/°/s 7±0.5
3 Operating temperature ℃ -40~+60
4 Measuring range °/s -250~+250
5 Output polarity —— Clockwise rotation outputs positive voltage
6 Supply voltage v +5
7 Random vibration —— 6.06g,20~2000Hz



 Outline and installation dimensions
Overall dimension (mm): 82 × 82 × 20 (L × W × H);
Installation dimension (mm): (60.8 ± 0.1) × (60.8 ± 0.1) (L × W), Φ3.6mm × 4, As shown.


Low Cost VG910 Similar Optical Gyroscope Single Axis 0



Company information
Low Cost VG910 Similar Optical Gyroscope Single Axis 1
Low Cost VG910 Similar Optical Gyroscope Single Axis 2
