Micro-Nano Integrated Fiber Optic Gyro for Miniaturized Industrial Use

Name: Micro-Nano Integrated Fiber Optic Gyro for Miniaturized Industrial Use
Brand: Shenzhen Fire Power Control Technology Co., LTD
SKU: MFOG-091A
Price: 1350 USD
Availability: InStock

Brand Name:	Firepower
Model Number:	MFOG-091A
MOQ:	1
Price:	1350 USD
Payment Terms:	T/T,L/C,Western Union
Supply Ability:	100 pcs

Detail Information

Product Description

Detail Information

Place of Origin:

CHINA

Certification:

Range:

±300°/s

Scale Factor:

7±0.7mv/°/s

Zero Bias Stability:

≤2°/H, 10s, 1σ

Zero Bias Repeatability:

≤2°/H, 1σ

Power Supply:

5+0.15V

Power Consumption:

≤0.7W

Packaging Details:

Sponge&Box

Supply Ability:

100 pcs

Highlight:

Single Axis Turntable

Inertial Navigation Systems Turntable

Performance Testing Turntable

Product Description

Micro-Nano Integrated Fiber Optic Gyro for Miniaturized Industrial Use

Product Description

MFOG-091A micro-nano fiber optic gyroscope is an angular rate sensor integrating optics with digital output, mechanics and electronics. Based on the Sagnac effect, it incorporates various micro-nano fiber devices to detect, process and feed back the phase difference generated by two beams of light propagating in opposite directions.

This product consists of optical path components, circuit components and structural components. Key features include:

Simple structure with no moving or wear parts
Fast start-up capability
Compact size and lightweight design
Ideal for attitude control and measurement applications

Technical Parameters

Serial number	Project	Performance indicators
1	Range (°/s)	±300
2	Scale factor	7±0.7mv/o/s
3	Scale factor nonlinearity (ppm)	≤1000
4	Zero-bias stability (10s, 1σ, °/H)	≤2
5	Zero-bias repeatability (1σ, °/H)	≤2
6	Angular random walk (°/H 1/2)	≤0.04
7	Zero bias (°/s)	≤0.05
8	Bandwidth 3dB Band Width (Hz)	≥450
9	Power supply (V)	5+0.15
10	Power Consumption (W)	≤0.7
11	Dimension (mm)	φ24X51.6
