Single-Axis Rotary Test Turntable For Aerospace And Defense Calibration

Name: Single-Axis Rotary Test Turntable For Aerospace And Defense Calibration
Brand: Shenzhen Fire Power Control Technology Co., LTD
SKU: 1LT400-W
Price: 5,000.00 USD
Availability: InStock

Brand Name:	Firepower
Model Number:	1LT400-W
MOQ:	1
Price:	negotiable
Payment Terms:	L/C, T/T
Supply Ability:	10 pcs/5 months

Detail Information

Product Description

Detail Information

Place of Origin:

CHINA

Certification:

Product Name:

Inertial Sensor Test Turntable

Structural Form:

Vertical

Load Capacity:

50kg/70Kg(optional)

Load Plate Size:

Ø500mm

Flatness Of Table:

0.03 Mm

Computer Port:

RS232

Table Height:

650mm

Face Runout:

0.05mm

Rotary Accuracy:

±1~3''

Position Accuracy:

±1~3''

Packaging Details:

Wooden Box

Supply Ability:

10 pcs/5 months

Highlight:

Aerospace Rotary Test Turntable

Defense Rotary Test Turntable

Single Axis Rotary Test Turntable

Product Description

Single-Axis Rotary Test Turntable for Aerospace and Defense Calibration

Single-axis multi-function turntable is a mature and finalized precision single-axis rate test equipment, which is mainly used for various position, rate and swing tests and detection of rate gyroscope and its inertial measurement unit. After the temperature control box, the temperature control system, the auxiliary shaft and other parts are selected, the turntable can also be applied to the performance test of the inertial navigation device and the inertial navigation system under the low temperature condition. The supporting computer of the turntable has the function of storing the data related to the operation of the turntable, such as the real-time value of time, turntable position, speed and temperature of the turntable body, and has the function of outputting the data in real time through the string, and can control the turntable and the temperature through the external computer (through the string).

Technical Parameter

Index	1LT400-W
Structural form	Vertical & Horizontal(Optional)
Maximum load weight	50/70KG Optional
Table size	Φ700mm
Mesa ﬂatness	0.03mm
Table height	650mm
Rotation accuracy	±1~3″
Angular position range	±0〜 ±360°
Angular position accuracy	±1~3″
Angular resolution	0.0001°
Angular rate range	0.001〜10000°/s
Angular rate accuracy	ω＜1°/s 1<ω＜10°/s 10<ω°/s
Speed smoothness	1×10⁻³ 1×10⁻⁴ 5×10⁻⁵
Max. angular acceleration	3000°/s²(Optional)
Rocking function	Optional
Rate resolution	0.0001°
Slip ring number	10~50(Optional)
System bandwidth	5~80Hz(Optioanl)
Slip-ring voice	≤±0.01V
Tank range	-60~+100℃
Tempe. control accuracy	±0.5℃
Tempe. uniformity	2℃
