Low Cost Mems Integrated Navigation System with RS232/RS422 Output

Brand Name:	FIREPOWER
Model Number:	INS500D
MOQ:	1
Price:	7000$
Payment Terms:	L/C,T/T,Western Union
Supply Ability:	500/month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Heading Accuracy:

0.1°

Attitude Accuracy:

0.1°

Gyro Range:

±500°/s

Gyro Zero Bias Stability:

4°/h

Acc Range:

±16g

Acc Zero Bias Stability:

0.2mg

Vibration:

20~2000Hz

Weight:

≤150g

Communication Interface:

PPS, Event, RS232, RS422, CAN

Horizontal Velocity Accuracy:

0.1m/s

Packaging Details:

sponge+box

Supply Ability:

500/month

Highlight:

RS422 Mems Integrated Navigation System

Low Cost Mems Integrated Navigation System

RS232 Mems Integrated Navigation System

Product Description

Product Description

INS100E integrated navigation system (hereinafter referred to as integrated navigation system) has built-in high-performance MEMS gyroscope and accelerometer, which can receive internal GNSS data, realize multi-sensor fusion and integrated navigation solution algorithm, and have short-term inertial navigation capability when GNSS is invalid.

The product has high reliability and strong environmental adaptability. By matching different software, the product can be widely used in the fields of industry unmanned motion carrier, unmanned vehicle, unmanned ship, communication in motion, mapping, stable platform and so on.

The integrated navigation system can carry out integrated navigation by using the satellite navigation information received internally, and output the pitch, roll, heading, position, speed, time and other information of the carrier; After losing the satellite signal, it outputs the position, velocity and attitude information of inertial solution, and has a certain navigation accuracy maintenance function in a short time.

Technical Parameters

Project		Metrics (RMS)	Remark
Heading accuracy	GNSS valid ①	0.1°
Heading accuracy	Heading holding	0.2°/min	GNSS failure
Attitude accuracy	GNSS is valid	0.1°	Single-point L1/L2, RTK
Attitude accuracy	Attitude holding	0.2°/min	GNSS failure
Positioning accuracy	Horizontal, GNSS valid; RTK	1.5m；1cm+1ppm	Single point L1/L2; Differential
	Elevation, GNSS valid; RTK	2.5m；2cm+1ppm	Single point L1/L2; Differential
	Position holding, GNSS failure	20m	Unlocked for 60s
Horizontal velocity accuracy	GNSS is valid	0.1m/s	Single-point L1/L2,RTK
Gyroscope	Measuring range	±500°/s
Gyroscope	Zero bias stability	4°/h	Allan variance
Accelerometer	Measuring range	±16g	Customizable 200 g
Accelerometer	Zero bias stability	0.2mg	Allan variance
Satellite board	Cold start	< 30 seconds	Open environment
	Hot start	5 seconds	Open environment
	Type of receiver	BDS B1I/B2I/B3I GPS L1C/A/L2P (Y)/L2C/L5 GLONASS G1/G2 Galileo E1/E5a/E5b QZSS L1/L2/L5
Communication interface	RS232	Route 2
Communication interface	RS422	Route 1
Electrical characteristics	Voltage	9~36VDC
	Power consumption	≤3W
	Ripple	100 mV	P-P
Structural characteristics	Size	80 mm×53 mm×23mm
Structural characteristics	Weight	≤150g
Use environment	Operating temperature	-40℃~+60℃
	Storage temperature	-45℃~+65℃
	Vibration	20~2000Hz,6.06g
	Impact	30g,11ms
	Degree of protection	IP65
Reliability	MTBF	30000h
	Life span	> 15 years
	Continuous working time	>24h
① Effective 2m baseline of dual antenna, or dynamic alignment of single antenna
