products details

Created with Pixso. Home Created with Pixso. Products Created with Pixso.
Fiber Optic Gyro
Created with Pixso.

VG191A Fiber Optic Gyroscope Sensor Replacement Gyro Senosor Better Performance and Cheaper

Name

VG191A Fiber Optic Gyroscope Sensor Replacement Gyro Senosor Better Performance and Cheaper

Brand Name: Firepower
Model Number: MFOG-24
MOQ: 1
Price: 1350$
Payment Terms: L/C,D/P,T/T,Western Union
Supply Ability: 500/month
Detail Information
Product Description
Detail Information
Place of Origin:
China
Measuring Range:
±500°/s
Zero-bias Stability( (10s, 1σ):
≤1.5°/h
Angular Random Walk:
≤0.03°/h
Bandwidth:
≥300Hz
Zero-bias Repeatability( (1σ):
≤1.5°/h
Scale Factor Nonlinearity:
≤300ppm
Dimension:
φ24X39mm
Power Supply:
5V
Packaging Details:
Sponge + Carton
Supply Ability:
500/month
Product Description
VG191A Fiber Optic Gyroscope Sensor Replacement Gyro Senosor Better Performance and Cheaper
Product Overview

The MFOG-091A Micro-Nano Fiber Optic Gyroscope is a high-precision angular rate sensor designed as a direct replacement for the Fizoptika VG191A. This advanced sensor integrates optical, mechanical, and electronic technologies to deliver accurate and reliable angular velocity measurements.

Key Features
  • Based on the Sagnac effect for precise angular motion detection
  • Compact and lightweight design with φ24×39mm dimensions
  • Advanced micro-nano fiber components for enhanced sensitivity
  • No moving parts for fast start-up and minimal maintenance
  • Robust construction for demanding environments
  • 5V power supply with ≤1.5W power consumption
Detailed Performance Parameters
Parameter MFOG-091A MFOG-091A-AN
Range (°/s) ±500 ±300
Scale factor nonlinearity (ppm) 300 ≤1000
Zero-bias stability (1σ, °/h) ≤1.5 ≤2
Angular random walk (°/h 1/2) ≤0.03 ≤0.04
3dB Band Width (Hz) ≥300 ≥450
Product Components
  • Optical path assembly
  • Detection and control signal circuit board
  • Optical fiber ring skeleton
  • Shell and structural components
Applications

Ideal for attitude control and motion sensing in:

  • Unmanned aerial vehicles (UAVs)
  • Autonomous navigation systems
  • Robotics platforms
  • Aerospace applications
Product Images
VG191A Fiber Optic Gyroscope Sensor Replacement Gyro Senosor Better Performance and Cheaper 0
VG191A Fiber Optic Gyroscope Sensor Replacement Gyro Senosor Better Performance and Cheaper 1
