MFOG Fiber Optic Gyroscope for Accurate Measurement in Dynamic Environments

Name: MFOG Fiber Optic Gyroscope for Accurate Measurement in Dynamic Environments
Brand: Shenzhen Fire Power Control Technology Co., LTD
SKU: MFOG-24
Price: 695.00 USD
Availability: InStock

Brand Name:	Firepower
Model Number:	MFOG-24
MOQ:	1
Price:	650~740
Payment Terms:	L/C,T/T
Supply Ability:	500/month

Detail Information

Product Description

Detail Information

Place of Origin:

CHINA

Range:

±500°/s

Zero-Bias Stability:

≤1.5°/h

Angular Random Walk:

≤0.03°/h^(1/2)

3dB Bandwidth:

≥300 Hz

Scale Factor Nonlinearity:

300 Ppm

Power Consumption:

≤1.5W

Packaging Details:

sponge/box

Supply Ability:

500/month

Highlight:

fiber optic gyroscope for dynamic environments

IMU gyroscope with accurate measurement

fiber optic gyro for precise navigation

Product Description

MFOG Fiber Optic Gyroscope for Accurate Measurement in Dynamic Environments

The MFOG-24 features a solid-state design that integrates optical fibers, electronics, and mechanical components to measure angular rates with exceptional precision. This innovative design eliminates mechanical wear, ensuring maintenance-free operation and long-term reliability.

Applications

Airborne navigation systems
Marine navigation equipment
Vehicle attitude control systems
Industrial automation control

Main Performance Parameters

Serial Number	Project	MFOG-24	MFOG-24-AN
1	Range (°/s)	±500	±300
2	Scale Factor	3600 (LSB/o/s)	7mv/o/s
3	Scale Factor Nonlinearity (ppm)	300	≤1000
4	Zero-Bias Stability (10s, 1σ, °/h)	≤1.5	≤2
5	Zero-Bias Repeatability (1σ, °/h)	≤1.5	≤2
6	Angular Random Walk (°/h 1/2)	≤0.03	≤0.04
7	Zero Bias (°/s)	≤0.02	≤0.05
8	3dB Band Width (Hz)	≥300	≥450
9	Power Supply (V)	5+0.15	5+0.15
10	Power Consumption (W)	≤1.5	≤0.7
11	Dimension (mm)	φ24X39
