| Gyro Range | ±300°/s |
|---|---|
| Random Walk | 0.05 °/h |
| Gyro Bias Stability | ≤0.3°/h(1σ) |
| ACC Range | ±50g |
| Pitch Angle Holding Accuracy | ≤0.2°/h |
| Product Name | Fiber Optic Inertial Navigation System |
|---|---|
| Gyro Range | ±500°/s |
| Gyro Zero Bias Stability | ±0.02°/h |
| Random Walk | ≤0.0015°/√h |
| Gyro Bandwidth | >300Hz |
| Product Name | Integrated Navigation System With GNSS |
|---|---|
| Heading Precision | 0.1deg (rms) |
| Attitude Accuracy | 0.1deg (rms) |
| Horizontal Velocity Accuracy | 0.1m/s（RMS） |
| Gyro Range | ±450°/s |
| Product Name | Integrated Navigation System With Accelerometer |
|---|---|
| Heading Accuracy | 0.1deg (rms) |
| Attitude Accuracy | 0.1deg (rms) |
| Horizontal Velocity Accuracy | 0.1m/s |
| Gyro Range | ±500°/s |
| Product Name | Integrated Navigation System With GPS |
|---|---|
| Heading Accuracy | 0.2 ° |
| Attitude Accuracy | 0.05°（RMS） |
| Gyro Range | ±400°/s |
| Gyro Zero Bias Stability | ≤0.3°/h |
| Product Name | INS With MEMS |
|---|---|
| Heading Accuracy | 0.1deg (rms) |
| Attitude Accuracy | 0.05°deg (rms) |
| Accelerometer Range | ±16g |
| Accelerometer Zero Bias Stability | ≤100µg |
| Product Name | INS Navigation System |
|---|---|
| Positioning Accuracy | 1.5nm/h |
| Heading Accuracy | 0.1° |
| Attitude Accuracy | 0.03° |
| Speed Accuracy | 0.1m/s(RMS) |
| Product | FOG INS |
|---|---|
| North-seeking Accuracy | ≤0.06° |
| Azimuth Accuracy | ≤0.02° |
| Speed Accuracy | ≤0.03m/s |
| Position Accuracy | 2cm+1ppm（RMS） |
| Product | FOG INS |
|---|---|
| North-seeking Accuracy | ≤0.03° |
| Azimuth Accuracy | ≤0.02° |
| Speed Accuracy | ≤0.03m/s |
| Position Accuracy | ≤2m/RTK 2cm(CEP) |
| Product | FOG INS |
|---|---|
| Gyro Range | 500°/s |
| Gyro Resolution | ≤0.01°/h |
| Gyro Bias | ±0.02°/h |
| Gyro Bias Stability | ≤0.01°/h（1σ） |
