Simulating Vibration Table Test Equipment 50ppm Centrifugal Acceleration Accuracy

Simulating Vibration Table Test Equipment 50ppm Centrifugal Acceleration Accuracy
Features Gallery Product Description Request A Quote
Product Name: Vibration Simulating Table
Acceleration Range: 0g~55 G
Centrifugal Nominal Radius: 1.5 M
Time To Reach Full Acceleration: 75s
Rotary Rate Accuracy: ≤ ± 10 Ppm
Rotary Rate Repeatability: ≤ ± 10 Ppm
High Light:

Simulating Vibration Test Table


Vibration Table Test Equipment 50ppm


Acceleration Vibration Table Test Equipment

Basic Infomation
Place of Origin: CHINA
Brand Name: AVIC
Model Number: CTF-700
Payment & Shipping Terms
Packaging Details: carton with sponge
Delivery Time: 10 days for sample
Payment Terms: T/T, L/C
Supply Ability: 1/5 months
Product Description

acceleration test table, high precise vibration simulating table


working conditions

Power supply 380V±10%; 50Hz±5Hz

Environment temperature 20℃±5℃

Relative humidity ≤85%


The centrifuge is composed of a mechanical platform, a measurement and control cabinet, and an industrial computer. It is mainly used for calibration and acceleration stress screening tests, and has smooth speed control capabilities.

The equipment adopts a box type, the box cover is made into a half-open (flip type) state, and the box cover is closed when the centrifuge is working. To ensure safety, a tact switch is provided at the cover of the box. When the cover is not covered, the device cannot be powered on.


Item Index Remark
Table top / Boom arm Boom arm
Centrifugal acceleration range 0g~55 g
Centrifugal nominal radius 1.5 m
Centrifugal acceleration accuracy Better than 50ppm in full range
Time to reach full acceleration 75s
Rotary rate accuracy(360°average) ≤ ± 10 ppm
Rotary rate repeatability (360°average) ≤ ± 10 ppm
Test payload quantity 2
Max payload 40 kg/payload balance
Slipring number 25 rings
Slipring current nominal value 3A/ring
Dynamic resistance change value 10mΩ
Slipring working voltage nominal value 250VDC



Mechanical structure

The centrifuge adopts a box-type flip cover design, and a travel switch is set at the box cover to ensure that the equipment cannot be powered on when the box cover is not tightly closed, which improves the safety protection of the operator.
