Quartz Flexure Accelerometer

High Performance Single Axis Quartz Accelerometer Vibration Sensor for Oil and Gas Industry

Name: High Performance Single Axis Quartz Accelerometer Vibration Sensor for Oil and Gas Industry
Brand: Shenzhen Fire Power Control Technology Co., LTD
SKU: AV1-01
Price: 1,250.00 USD
Availability: InStock

Brand Name:	Firepower
Model Number:	AV1-01
MOQ:	1
Price:	negotiable
Payment Terms:	T/T
Supply Ability:	500/month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Function:

Vibration Test

Measuring Range:

±50g

Threshold Value:

5μg

Deviation Value K0/k1:

≤(±3 Mg)

Scale Factor K1:

1.3±0.2 MA/g

Weight:

≤80g

Shock:

100g,5ms,1/2sin

Power Supply:

±12~±15V

Current Consumption:

≤±20mA

Bandwidth:

800~2500 Hz

Packaging Details:

sponge/box

Supply Ability:

500/month

Highlight:

Quartz Flexible Acceleration Sensor

Torque Feedback Inertial Navigation Sensor

Quartz Flexible Inertial Navigation Sensor

Product Description

High Performance Single Axis Quartz Accelerometer Vibration Sensor for Oil and Gas Industry

Key Specifications

Attribute	Value
Function	Vibration test
Measuring range	±50g
Threshold value	5μg
Deviation value k0/k1	≤(±3 mg)
Scale factor k1	1.3±0.2 mA/g
Weight	≤80g
Shock	100g,5ms,1/2sin
Power supply	±12~±15V
Current consumption	≤±20mA
Bandwidth	800~2500 Hz

Product Overview

The AV1 Series quartz flexibility accelerometer is a high-accuracy inertial grade sensor with exceptional long-term stability, repeatability, start-up performance, environmental adaptability, and reliability. This cost-effective solution provides linear current output proportional to the force received, allowing users to select appropriate sampling resistors for optimal accuracy.

The built-in temperature sensor enables linear current output adjustment with temperature changes (optional compensation available). Suitable for both static and dynamic testing applications, this sensor meets standard vibration measurement requirements in demanding industrial environments.

Technical Specifications

Parameter	AV1-01 Specification
Measuring range	±50g
Threshold value	5μg
Deviation value k0/k1	≤(±3 mg)
Scale factor k1	1.3±0.2 mA/g
Second-order nonlinear coefficient K2	≤±20μg /g²
0g 4 h short-term stability	≤10 μg
1g 4 h short-term stability	≤10 ppm
Deviation value repeatability σk0 (1σ,1 month)	≤10 μg
Scale factor repeatability σk1/k1 (1σ,1 month)	≤15ppm
Nonlinear coefficient repeatability σk2/k1(1σ,1 month)	≤±10 μg /g²
Deviation value temperature coefficient	≤±10 μg /ºC
Scale factor temperature coefficient	≤±20 ppm /ºC
Noise (840Ω sampling resistance)	≤5mv
Natural frequency	400~800 Hz
Bandwidth	800~2500 Hz
Vibration resistance	5g(20-2000Hz)
Shock resistance	100g,5ms,1/2sin
Operating temperature range	-40 to +85ºC
Storage temperature range	-60 to +120ºC
Power supply	±12~±15V
Current consumption	≤±20mA
Temperature sensor	Available in two types (with/without)
Dimensions	Ф25.4X30mm
Weight	≤80g

Product Diagram

Installation Guidelines

The flange surface of the sensor serves as the installation reference surface for proper mounting.

Handling & Safety Precautions

This sensor is a precision instrument - handle with care and avoid dropping or impact
Do not exceed specified shock/vibration limits (100g,5ms,1/2sin)
Package with ≥20mm buffer foam during transport, securing sensor to prevent movement
When shipping multiple units, prevent contact between sensors
Verify all pin connections before powering on
Store in original packaging in dry, ventilated environment
Observe proper electrostatic discharge (ESD) protection measures
