Home Products

Accelerometer Gyro Sensor

Low Cost OEM MEMS gyroscope chips Factory Price for Inertial Measurement Unit

Name: Low Cost OEM MEMS gyroscope chips Factory Price for Inertial Measurement Unit
Brand: Shenzhen Fire Power Control Technology Co., LTD
SKU: MGC150- P05
Price: 1500 USD
Availability: InStock

Brand Name:	Firepower
Model Number:	MGC150- P05
MOQ:	1
Price:	1500$
Payment Terms:	L/C,D/A,D/P,T/T,Western Union
Supply Ability:	500/month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Range:

150°/s

Bias Stability (10 S Smoothing):

0 .5°/h

Bias @ 25℃:

15°/h

Angle Random Walk:

0.06°/√ H

Bias Repeatability:

2°/h

Scale Factor Repeatability:

30ppmx

Non - Linearity @ Full Scale (FS):

100ppm

Bandwidth:

30Hz

Packaging Details:

BOX+Sponge

Supply Ability:

500/month

Product Description

Low Cost OEM MEMS Gyroscope Chips for Inertial Measurement Units

Key Specifications

Attribute	Value
Range	150°/s
Bias Stability (10 s smoothing)	0.5°/h
Bias @ 25℃	15°/h
Angle Random Walk	0.06°/√h
Bias Repeatability	2°/h
Scale Factor Repeatability	30ppmx
Non-linearity @ Full Scale (FS)	100ppm
Bandwidth	30Hz

Product Overview

The MGC series single-axis MEMS gyroscopes deliver highly stable and low-noise angular velocity outputs in a compact ceramic package with fully digital interface. With bias stability as low as 0.5 dph, angle random walk down to 0.06°/√h, and wide bandwidth up to ≥100 Hz, these sensors provide exceptional precision and long-term repeatability.

Technical Parameters

Parameter	MGC150-P05	MGC500-P1	MGC500-P2	MGC500-P3	Unit
Range	150	500	500	500	dps
Bias @ 25℃	15	45	45	45	dph
Noise @ 10Hz	0.001	0.0012	0.0012	0.0012	mdps/√Hz
Bias Stability (10 s smoothing)	0.5	1.0	2.0	3.0	dph
Angle Random Walk	0.06	0.08	0.08	0.08	°/√h
Bias Repeatability (Weekly)	2	2	2	2	dph
Scale Factor	38550	11185	11185	11185	LSB/dps
Scale Factor Repeatability (Weekly)	30	30	30	30	ppm
Non-linearity @ Full Scale (FS)	100	100	100	100	ppm
Non-linearity @ 200 dps	50	50	50	50	ppm
Bandwidth	30	≥100	≥100	≥100	Hz

Typical Applications

Inertial Navigation Systems
Platform Stabilization
Attitude and Heading Reference System
Precision Agriculture and Industrial Automation
UAV and Autonomous Vehicle Systems

These high-precision MEMS gyroscopes are particularly suitable for drone and unmanned systems' orientation and attitude control, as well as for integration into advanced navigation systems such as IMU and INS.
