Gyro North Finder
Created with Pixso.

2025 New Generation Fiber Optic Gyro North Finder ≤ 0.7° accuracy

2025 New Generation Fiber Optic Gyro North Finder ≤ 0.7° accuracy

2025 New Generation Fiber Optic Gyro North Finder ≤ 0.7° accuracy

Brand Name: Firepower
Model Number: NF102
MOQ: 1
Price: 4000$
Payment Terms: L/C,T/T
Supply Ability: 500/Month
Detail Information
Product Description
Detail Information
Place of Origin:
China
Azimuth Error:
±0.7°
Navigation Tracking Error:
±0.7°
Tilt Adaptability:
±15°
Power Consumption:
≤1W
Output Mode:
RS422/RS232
Dimension:
60X60X60mm
Product Weight:
≤ 400 G
Operating Temperature:
-30℃~+65℃
Packaging Details:
Sponge+ Carton
Supply Ability:
500/Month
Highlight:

fiber optic gyro north finder

,

high accuracy gyro north finder

,

2025 gyro north finder

Product Description
2025 New Generation Fiber Optic Gyro North Finder ≤ 0.7° Accuracy
Product Specifications
  • Supply voltage: 9 ~ 12 V
  • Product dimensions: 60×60×60/46×53 (4×M4)
  • Product weight: ≤ 400 g
  • Operating temperature: -30℃ to +65℃
  • Storage temperature: -55℃ to +85℃
Main Parameter Indexes
Project Unit Industrial grade N F -102
Output mode
RS422/RS232
Connector
J30JM-15ZKP
Power consumption W ≤1
Azimuth error ° ±0.7
Navigation tracking error ° ±0.7 (≤5min, rotation speed ≤10°/s)
Tilt adaptability ° ±15
J30JM-15ZKSP Wiring Definition
Serial number Definition Type Interface
1 R- Input RS422 user interface
2 R+ Input
3 T+ Output
4 T- Output
5 IO+ Input External North Seeking Switch
6 IO- Output
7 +12VGND Input Power ground
8 +12VGND Input
9 RS232_GND GND RS232 user interface
10 RS232_TX Output
11 RS232_RX Input
12 NC Reserved
13 NC Reserved
14 +12V Input 12 Power supply input
15 +12V Input
